2000L Trailed Water Bowser for on-site tow
Irrigation, water transport and firefighting systems that are reliable and ready to use.
- Trailers that are fully outfitted and ready to work.
- Saves time at mobile watering tasks and reduces water wastage.
- There will be less labor and hassle. Less manpower is required.
- Models that are appropriate for your small machinery
- Adaptable to your requirements.
- Solutions that are dependable and proven.
- Reduce your carbon emissions with optional Zero-Emission pump system
- Tow with lawn tractor, ATV, UTV, utility vehicle, small tractor, loader or other small machinery.
Foresteel FTW-2000 Watering Trailer Benefits
Fully self-contained towable irrigation system
Reliable and simple to deal with
Everything needed for irrigation operations is included in this ready-to-work system
Because of the embedded forklift pockets, it is simple to lift and load
Pump that is both powerful and efficient
Fertilizers, insecticides, and other chemicals can be mixed and solved in the tank
Emission-free and quiet operation with optional electrical pumping system
Compact size and low self weight, easy to tow and maneuver
Sloshing baffles available as an option
Integrated ventilation valves on the top hatch for automatic air access
Thanks to the modular design chassis and forklift pockets, the chassis can be unmounted and the unit used as an irrigation platform
Used by many professionals with great results
Technical data
Tank capacity | 2000 L |
---|---|
Dimensions | L 3300 mm x W 1960 mm x H 1700 mm |
Weight (empty) | 490 kg |
Weight (full) | 2490 kg |
Construction | Durable UV resistant PE plastic tank on galvanized steel frame with forklift pockets (4-way lifting). |
Pumping system (Gasoline) | Gasoline Honda WX Easy Start water pump, max 240 l/min |
Work time (Gasoline) | Work time at full throttle 1.3 hours. Equals over 18000 liters. |
Pumping system (Electric) | 12V electrical pump, 26.5 l/min max capacity, integrated filter. |
Work time (Electric) | Work time approx 3 hours with full battery. Equals over 4000 liters. |
Charging (Electric) | Integrated charge level indicator with charger plug on battery pack. |
Hose | 15m 3/4" hose on automatic reel (can be substituted with 20m 1/2” hose on request) |
Suction/filling | 7m suction hose with sieve and float (excluded on 12V Electric pump systems). |
Chassis | Modular steel chassis with bolted axle and drawbar. D50 mm ball coupling. Wheeled parking foot. Wide turf tires. |
Extras | Baffles against sloshing I 12V Electric pump, Watering tools, Flow Meter, Additional Inlet |
Delivery information | Delivered to door with tail lift truck. Packaged on pallet, with drawbar and wheels unassembled for transport. Easy assembly. Instructions included. No unloading equipment needed by customer for receipt (Unless requested for delivery fully assembled) |
Standard equipment
PE plastic tank on steel underframe with forklift pockets
DetailsPE plastic tank on steel underframe with forklift pockets
Strong and UV resistant PE plastic tank without baffles
DetailsStrong and UV resistant PE plastic tank without baffles
15m 3/4″ watering hose on automatic reel with adjustable spray nozzle
Details15m 3/4″ watering hose on automatic reel with adjustable spray nozzle
Honda WX15 240 l/min easy start gasoline engine pump
DetailsHonda WX15 240 l/min easy start gasoline engine pump
Valve system to use pump also for filling the tank from lake or pond
DetailsValve system to use pump also for filling the tank from lake or pond
7m suction hose with sieve and float
Details7m suction hose with sieve and float
380 mm diameter top hatch
Details380 mm diameter top hatch
Wide low-pressure wheels 26x12x12
DetailsTrailer chassis for 2000L version
DetailsTrailer chassis for 2000L version
Optional equipment
Baffles against sloshing (Internal walls)
Electric pump, 12V 26.5l/min max, with battery pack
Automatic reel with 30m 1” or 40m ¾” watering hose
40 mm Towing eyelet
Remote controlled irrigation boom
- 2 Irrigation Boom sets with water breakers (shower heads);
- Wiring set with quick-plug connections
- Hoses and brackets with assembly instructions
- All in a easy to install set.
Easy and simple!
FTW-2000 Trailed Watering Bowser can help you with your daily tasks and solve several problems.
We have worked closely with customers and redesigned the mobile watering solution so it can be easily lifted, transported and used by anyone with basic knowledge. Simplified on-tank instructions make using the system easy and intuitive. Carefully chosen reliable components make it one of the most reliable and trustworthy options available on the market.
Problem
- Traditional watering methods, on average, squander up to 50% of the water they consume owing to inefficiencies in irrigation, evaporation, and overwatering.
- Increasing frequency of high temperatures and droughts demand more efficient irrigation.
- Limitations on tap water usage for irrigation in multiple municipalities and countries
- You have watering deficits and want to maximize efficient water usage.
- Runoff, wind, and evaporation squander around half of all irrigation water.
- Short time-windows allowed for daily irrigation tasks due to weather or other restrictions.
- You're always thinking there should be a better way!
The solution offered by Foresteel
- A range of portable watering tanks that is ready to use in minutes and will help you get through your errands faster.
- Water tanks made of durable plastic and efficient pump systems are mounted on a multipurpose steel base with forklift compartments.
- Towable with any small machinery available like lawn tractor, ATV, UTV, utility vehicle, small tractor, loader or other small machinery.
- Easy to use by anyone with no special training needed. The only water bowser you need.
- The time-saving, ready-to-use bundle that will make your errands go faster.
Benefit
- Seasonal irrigation duties can be completed in less time and for less money.
- Minimize water wastage upto 50% and cut workforce.
- Make work duties in public spaces more convenient and less disturbing.
- Less work and hassle. Cut workforce requirements upto 60%.
- Fully autonomous and mobile system ready for work anywhere.
- Reduce the potential for turf damage caused by large industrial watering trailers.
- Tow with any small machinery available like lawn tractor, ATV, UTV, utility vehicle, small tractor, loader or other small machinery.
- Your own unit is always available.
- With the optional Zero Emission electrical pumps, you may go emission-free.
Customer stories
A few examples of how our products help our customers with their needs.
Emanuel G. Vinyard manager from Manciano Italy
„I am very happy with the product, it’s very well built with care and good material. Before the water trailer I subcontracted the job of irrigating to an external company, but the subcontractor was not always available and I had to beg him to do the work. No more begging! The product is of high quality and construction. A very pleasant experience, nice people, good support. I’d be happy to do more business with Foresteel.“
A small selection of customers…
- Vineyards and horticulture companies
- Garden centers
- Church-cemetery managers etc.
- Golf centers
- Municipalities
- Landscaping contractors
- Manors
- Sports grounds and facilities
- Camping centers
- Schools and Universities
- Hotels and spa centers
